| Category | Parameter Item | Parameter Content |
|---|---|---|
| Specification | LED Chips | LangMingNaSi LED Chip 20W * 1PC |
| Specification | Material | Aluminum, Die-Casting PC Lens (Note: "Materieal" corrected to standard spelling "Material") |
| Specification | Operating Voltage | 9-32V DC |
| Specification | Mount | Bottom / Side Mount; Also mounts behind factory mirror using factory hardwares |
| Specification | Beam Pattern | Spot / Flood / Combo |
| Specification | PC Lens Select | Clear / Yellow |
| Specification | Housing & Brackets | Durable die-cast aluminum housing; Durable powder-coated steel brackets |
| Specification | Special Technology | Moisture Breather technology (reduces moisture build-up behind the lens) |
| Specification | Service Life | 50000 hours+ |
| Specification | Warranty Period | Two year warranty |
| Parameter | Size | 80*50*47mm |
| Parameter | Luminous Flux | 3630 LM |
| Parameter | Power | 20W (consistent with total power of LED Chip) |
| Specification | Waterproof Rating | IP68 |
| Operational Lumens Output | 3630lm | Vibration | ||
| Colour Temperature | 6000-6500 K | Lens | PC | |
| Norminal Voltage DC | 12 - 24 V | Body/Housing | Aluminum | |
| Input Voltage DC | 9 - 32 V | Weight | 285g | |
| Power Consumption | 20W | IP Rating | IP68 | |
| Nominal Current at | 24V=0.8A,12V=1.6A | Salt Sprary Test | ISO 9227 240H | |
| Connector | Built-in Deutsch DT-2(2-pin) | EMC | E8 10R-0617152 Class 5 / Class 3 (For Select) | |
| Mount | Bottom Mount | Operating Temperatures | -40℃...+85℃（Full Power -40℃... +50℃） | |
| Shock | 60G | Part Numbers |
