| Category | Parameter Item | Parameter Value |
|---|---|---|
| Core Performance | Total Power | 45 Watts |
| Core Performance | Luminous Flux | 3150 Lumens |
| Core Performance | Operating Voltage | 9-36V DC |
| Core Performance | LED Configuration | Each light contains 5W High Intensity LEDs (total 45W) |
| Accessories | Included Components | Wiring harness with on/off switch |
| Physical Characteristics | Housing Material | Durable die cast aluminum |
| Physical Characteristics | Beam Type | Spot/Flood Beam |
| Physical Characteristics | Housing Color | Black |
| Installation & Dimension | Mounting Type | Bottom Mount |
| Installation & Dimension | Product Size (LWH) | 153*115*86mm |
| After-Sales | Warranty Period | 1 year |
| Physical Characteristics | Waterproof Rating | IP67 |
| Operational Lumens Output | 3150lm | Vibration | ||
| Colour Temperature | 6000-6500 K | Lens | PC | |
| Norminal Voltage DC | 12 - 24 V | Body/Housing | Aluminum | |
| Input Voltage DC | 9 - 32 V | Weight | g | |
| Power Consumption | 45W | IP Rating | IP68 | |
| Nominal Current at | 24V=1.8A,12V=3.7A | Salt Sprary Test | ISO 9227 240H | |
| Connector | Built-in Deutsch DT-2(2-pin) | EMC | E8 10R-0617152 Class 5 / Class 3 (For Select) | |
| Mount | Bottom Mount | Operating Temperatures | -40℃...+85℃（Full Power -40℃... +50℃） | |
| Shock | 60G | Part Numbers |
