| Category | Parameter Item | Parameter Value |
|---|---|---|
| Product Features | Power | 10 Watts |
| Product Features | Luminous Flux | 1200 Lumens |
| Product Features | Voltage | 9-36V DC |
| Product Features | LED Specification | 10 watt High Intensity LEDs |
| Product Features | Included Accessories | Includes wiring harness with on/off switch |
| Product Features | Housing Material | Durable die cast aluminum housing |
| Product Features | Beam Type | Spot/Flood Beam |
| Product Features | Housing Color | Black |
| Product Features | Mount Type | Bottom Mount |
| Product Features | Warranty | 1 year |
| Product Features | Waterproof Rating | IP67 Waterproof rating |
| Operational Lumens Output | 1200lm | Vibration | ||
| Colour Temperature | 6000-6500 K | Lens | PC | |
| Norminal Voltage DC | 12 - 24 V | Body/Housing | Aluminum | |
| Input Voltage DC | 9 - 32 V | Weight | g | |
| Power Consumption | 10W | IP Rating | IP68 | |
| Nominal Current at | 24V=3.0A,12V=0.8A | Salt Sprary Test | ISO 9227 240H | |
| Connector | Built-in Deutsch DT-2(2-pin) | EMC | E8 10R-0617152 Class 5 / Class 3 (For Select) | |
| Mount | Bottom Mount | Operating Temperatures | -40℃...+85℃（Full Power -40℃... +50℃） | |
| Shock | 60G | Part Numbers |
